Shape・・・ Type 27
Size
【Standard grinding wheel】
・Broad range of products, suitable for various metals
・Cost effective economical type
Part No. |
Size (mm) (Dia. x Thick x Hole size) |
Grain | Grit Size | Hardness | In Stock | Inner Qty. | Outer Qty. | Max. Operating Speed (min-1) |
Max. Operating Speed (m/s) |
||||
Steel | |||||||||||||
RAG1004-24M | 100x4x15 | A/WA | 24 | M | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG1004-24 | 100x4x15 | A/WA | 24 | P | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG1004-36M | 100x4x15 | A/WA | 36 | M | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG1004-36 | 100x4x15 | A/WA | 36 | P | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG100416-24 | 100x4x16 | A/WA | 24 | P | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG100416-36 | 100x4x16 | A/WA | 36 | P | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG1006-24M | 100x6x15 | A/WA | 24 | M | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-24 | 100x6x15 | A/WA | 24 | P | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-24S | 100x6x15 | A/WA | 24 | S | 25 | 100 | 13,750 | 72 | |||||
RAG1006-36M | 100x6x15 | A/WA | 36 | M | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-36 | 100x6x15 | A/WA | 36 | P | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-36S | 100x6x15 | A/WA | 36 | S | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG100616-24 | 100x6x16 | A/WA | 24 | P | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG100616-36M | 100x6x16 | A/WA | 36 | M | 25 | 100 | 13,750 | 72 | |||||
RAG100616-36 | 100x6x16 | A/WA | 36 | P | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1256-24M | 125x6x22 | A/WA | 24 | M | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1256-24 | 125x6x22 | A/WA | 24 | P | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1256-36M | 125x6x22 | A/WA | 36 | M | 25 | 100 | 11,000 | 72 | |||||
RAG1256-36 | 125x6x22 | A/WA | 36 | P | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1506-24M | 150x6x22 | A/WA | 24 | M | 〇 | 25 | 50 | 9,160 | 72 | ||||
RAG1506-24 | 150x6x22 | A/WA | 24 | P | 〇 | 25 | 50 | 9,160 | 72 | ||||
RAG1506-36M | 150x6x22 | A/WA | 36 | M | 25 | 50 | 9,160 | 72 | |||||
RAG1506-36 | 150x6x22 | A/WA | 36 | P | 〇 | 25 | 50 | 9,160 | 72 | ||||
RAG1806-24L | 180x6x22 | A/WA | 24 | L | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-24M | 180x6x22 | A/WA | 24 | M | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-24 | 180x6x22 | A/WA | 24 | P | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-36L | 180x6x22 | A/WA | 36 | L | 25 | 50 | 7,630 | 72 | |||||
RAG1806-36M | 180x6x22 | A/WA | 36 | M | 25 | 50 | 7,630 | 72 | |||||
RAG1806-36 | 180x6x22 | A/WA | 36 | P | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-36S | 180x6x22 | A/WA | 36 | S | 25 | 50 | 7,630 | 72 | |||||
RAG1808-24M | 180x8x22 | A/WA | 24 | M | 20 | 40 | 7,630 | 72 | |||||
RAG1808-24 | 180x8x22 | A/WA | 24 | P | 〇 | 20 | 40 | 7,630 | 72 | ||||
RAG1808-36 | 180x8x22 | A/WA | 36 | P | 20 | 40 | 7,630 | 72 | |||||
RAG2056-24M | 205x6x22 | A/WA | 24 | M | 25 | 50 | 6,700 | 72 | |||||
RAG2056-24 | 205x6x22 | A/WA | 24 | P | 〇 | 25 | 50 | 6,700 | 72 | ||||
RAG2056-36 | 205x6x22 | A/WA | 36 | P | 〇 | 25 | 50 | 6,700 | 72 | ||||
RAG2058-24M | 205x8x22 | A/WA | 24 | M | 20 | 40 | 6,700 | 72 | |||||
Stainless Steel/INOX, Alloy Steel | |||||||||||||
RAG1004-SUS36 | 100x4x15 | Stainless | 36 | L | 〇 | 25 | 200 | 13,750 | 72 | ||||
RAG1006-SUS24 | 100x6x15 | Stainless | 24 | L | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-SUS36 | 100x6x15 | Stainless | 36 | L | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1256-SUS24 | 125x6x22 | Stainless | 24 | L | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1256-SUS36 | 125x6x22 | Stainless | 36 | L | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1506-SUS24 | 150x6x22 | Stainless | 24 | L | 25 | 50 | 9,160 | 72 | |||||
RAG1506-SUS36 | 150x6x22 | Stainless | 36 | L | 〇 | 25 | 50 | 9,160 | 72 | ||||
RAG1806-SUS24 | 180x6x22 | Stainless | 24 | L | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-SUS36 | 180x6x22 | Stainless | 36 | L | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG2056-SUS24 | 205x6x22 | Stainless | 24 | L | 25 | 50 | 6,700 | 72 | |||||
Aluminum only | |||||||||||||
RAG1004-AL36 | 100x4x15 | Aluminum | 36 | M | 25 | 200 | 13,750 | 72 | |||||
RAG1006-AL24 | 100x6x15 | Aluminum | 24 | M | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1006-AL36 | 100x6x15 | Aluminum | 36 | M | 〇 | 25 | 100 | 13,750 | 72 | ||||
RAG1256-AL24 | 125x6x22 | Aluminum | 24 | M | 〇 | 25 | 100 | 11,000 | 72 | ||||
RAG1506-AL24 | 150x6x22 | Aluminum | 24 | M | 〇 | 25 | 50 | 9,160 | 72 | ||||
RAG1806-AL24 | 180x6x22 | Aluminum | 24 | M | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG1806-AL36 | 180x6x22 | Aluminum | 36 | M | 〇 | 25 | 50 | 7,630 | 72 | ||||
RAG2056-AL24 | 205x6x22 | Aluminum | 24 | M | 〇 | 25 | 50 | 6,700 | 72 |
○:Available
none:Build to order
