- Grinding
- High Speed
Shape ・・・ Type 27
Nature of Bond・・・BF
Size
- 180Ф
【Standard high-speed grinding wheel】
・Broad range of products, suitable for various metals
・Suitable for non-ferrous metal and non-metal materials
Specification
| Part No. |
Size (mm) (Dia. x Thick x Hole size) |
Grain | Grit Size | Hardness | In Stock | Inner Qty. | Outer Qty. | Max. Operating Speed (min-1) |
Max. Operating Speed (m/s) |
||||
| Steel, Cast Iron | |||||||||||||
| RK1806-24M | 180x6x22.23 | A | 24 | M | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-24 | 180x6x22.23 | A | 24 | P | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-24S | 180x6x22.23 | A | 24 | S | 25 | 50 | 8,480 | 80 | |||||
| RK1806-36 | 180x6x22.23 | A | 36 | P | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-AWA24M | 180x6x22.23 | A/WA | 24 | M | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-AWA24 | 180x6x22.23 | A/WA | 24 | P | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1808-24M | 180x8x22.23 | A | 24 | M | 〇 | 20 | 40 | 8,480 | 80 | ||||
| RK1808-24 | 180x8x22.23 | A | 24 | P | 〇 | 20 | 40 | 8,480 | 80 | ||||
| Stainless Steel/INOX, Alloy Steel | |||||||||||||
| RK1806-WA24M | 180x6x22.23 | WA | 24 | M | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-WA24 | 180x6x22.23 | WA | 24 | P | 〇 | 25 | 50 | 8,480 | 80 | ||||
| RK1806-WA36M | 180x6x22.23 | WA | 36 | M | 25 | 50 | 8,480 | 80 | |||||
| RK1806-WA36 | 180x6x22.23 | WA | 36 | P | 25 | 50 | 8,480 | 80 | |||||
| Aluminum, Brass, Non-ferrous (Gun Metal) Metal, Non-Metals (Stone, Glass) | |||||||||||||
| RK1806-C24M | 180x6x22.23 | C | 24 | M | 25 | 50 | 8,480 | 80 | |||||
〇：Available none：Build to order
