Shape ・・・ Type 27
Size
【Mini size Skill Touch wheel suitable for narrow area】
・Suitable for working in narrow area
・Suitable for various metals
Part No. |
Size (mm) (Dia. x Thick x Hole size) |
Grain | Grit Size | Hardness | In Stock | Inner Qty. | Outer Qty. | Max. Operating Speed (min-1) |
Max. Operating Speed (m/s) |
MS502-46 | 50x2x9.53 | - | 46 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS502-60 | 50x2x9.53 | - | 60 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS502-80 | 50x2x9.53 | - | 80 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS502-120 | 50x2x9.53 | - | 120 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS503-46 | 50x3x9.53 | - | 46 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS503-60 | 50x3x9.53 | - | 60 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS503-80 | 50x3x9.53 | - | 80 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS503-120 | 50x3x9.53 | - | 120 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS582-46 | 58x2x9.53 | - | 46 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS582-60 | 58x2x9.53 | - | 60 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS582-80 | 58x2x9.53 | - | 80 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS582-120 | 58x2x9.53 | - | 120 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS583-46 | 58x3x9.53 | - | 46 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS583-60 | 58x3x9.53 | - | 60 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS583-80 | 58x3x9.53 | - | 80 | - | 〇 | 25 | 250 | 22,910 | 60 |
MS583-120 | 58x3x9.53 | - | 120 | - | 〇 | 25 | 250 | 22,910 | 60 |
○:Available
none:Build to order
